Online X-RAY Chip Counter Machine X-Chip-A350

back

Online X-RAY Chip Counter Machine X-Chip-A350

Manufacturer: 1ClickSMT
Model: X-Chip-A350

Description

This X-RAY chip counter machine can greatly improve the production efficiency, to realize the automation and electronic components inventory management information, the main principle through X-ray penetrate the imaging principle of image information, for items of the SMT production materials, nondestructive testing, image import artificial intelligence algorithms computing, automatic rapid calculation material the actual number of the material.

System features:

Return of investment: 8~10 months;
In-line inspection, no manual operation needed;
Take the place of labour of 10~12 persons, efficient;
Able to connect to ERP/MES System;
Improve accuracy of storage.

Gallery

Specification

Scanning Size:

180 mm - 380 mm (400 mm optional)

Speed:

20, 35 seconds

TUBE Max Volt:

80 kV

TUBE max current:

4.5 mA

TUBE max power:

350 W

Reel size:

Minimal size of the CHIP 0201/01005

Reel height:

8 mm - 45 mm

Code Scanning Way:

Manually scanning/CCD automatic scanning(optional)

Database:

Connectible to ERP system or MES system

Sample Conveying:

Left to right/Right to left

Equipment weight:

350 kg

Equipment Size (LхWхH):

1300х1200x1970 mm

Power Supply:

220 V ±10%, 50/60 Hz

Power:

3 KW

Air Pressure:

0.5 Mpa

Working Temperature:

<40℃

Relative Humidity:

70%

Safety:

Comply to national safety scope - 1u Sv/h
